Product nameLiDAR-Mid-360
Laser wavelength905 nm
Eye safety levelClass 1 (IEC 60825-1:2014) Eye Safe
Range (@100 klx)40 m @10% reflectivity
70 m @80% reflectivity
Near blind spot≤10 cm
FOV360°x59
Ranging error (10)≤2 cm(@10 m);≤3 cm(@0.2 m)
Angle random error (10)0.15°
Point cloud output200,000 points/second
Point cloud frame rate10 Hz (typical)
Anti-crosstalk functionYes
Data network port100 BASE-TX Ethernet
Data synchronization methodEEE 1588-2008 (PTP V2), PPS (Pulse per Second), GPS (PPS+UTC)
False alarm rate (@100 klx)<0.01%
Working environment temperature-20°C~55°C
Storage environment temperature-40°C~85°C
Protection levelIP67
Power7W
Supply voltage range9~27VDC
Dimensions65x65x60 mm
WeightAbout 265g
